DESCRIPTION
Single component Nickel-CNT Acrylic conductive coating provides effective EMI/RFI shielding on plastic housings used in the electronics and computer industries. Using a suitable primer such ECP 522 this paint can also be applied to variety of metals
PHYSICAL PROPERTIES
Surface Resistivity at 30 micron 0.5 ohm/square or less
(2 thou) ASTM D257
Colour Dark Grey
Flash Point (Abel closed cup – 25 deg C
method IP 33/59)
Recommended Dry Film Thickness 50 micron (2 thou)
ASTM D 4138-82)
Specific Gravity 1.5 g/cc
Coverage per litre at 30 micron 7-10 square metres
Drying time: Touch 15 minutes
Full 12 hours
Adhesion (BS 3900 E6) Excellent
Pencil Hardness (ASTM D3363-74) H
Shelf Life 12 months from date of sale for unopened tin
Viscosity when thinned 1:1with 0.6p on a cone and plate
ECP 502/JSF024 thinners or 27-32secs on a B4 flow cup.
AVAILABILITY
ECP 504is available in 5litre/7kg cans or alternatively as an aerosol, ECP 554
METHOD OF USE
Surface Preparation: All contaminants including mould release, grease and dirt must be removed. Mask areas that do not require coating. A suitable primer may be necessary on certain substrates such as Polyethylene and Polypropylene, steel, aluminium etc.
Mixing and Application: Care must be taken to ensure the concentrate is thoroughly mixed to ensure all the solids are in suspension.
Spray Coating:- . ECP 504 may settle out and regular agitation is recommended during spray application. The paint should be diluted with thinner ECP 504 to suit local spray conditions. Typically, 2 parts of concentrate to 1part thinners can be used in a conventional gravity feed spray gun or, alternatively, a pressure pot with agitator. A gun Pressure of 30 psi is recommended. Two passes are normally required to give the optimum thickness and surface resistivity values.
Brush Coating:- Brush coat from the can or thinned to suit the application.
PRECAUTIONS
Highly Flammable – Keep away from sources of ignition – No Smoking (S16). Keep away from heat, sparks and open flames. Keep all containers closed when not in use.
Use Under Well Ventilated Conditions – Do not breath vapour (S23). Harmful by inhalation (R20). In case of insufficient ventilation – wear suitable respiratory equipment (S38), such devices must be used in accordance with the manufacturer’s instructions. For excessive vapour inhalation, remove to fresh air and summon medical attention.
Avoid Contact With Skin And Eyes (S24/25) – In case of skin contact, wash with soap and water, dry and apply work cream. Eye contact – flush with water for at least 15 minutes and seek medical attention. If accidentally swallowed, summon medical attention.
If you would like further information or assistance, please contact TBA Electro Conductive Products Ltd.
