ECP 534 SD Powder Coating

A static dissipative  powder coating, ECP 534 is based on a carboxylated polyester resin modified with epoxies.  Designed where the user requires electrostatic dissipative properties in addition to a superior decorative finish, e.g. static safe work benches, racks , trolleys etc..  It offers excellent flow, toughness and good chemical resistance.  A range of substrates may be coated.

A thermosetting powder coating based on selected solid polyester resins crosslinked with an epoxy curing system.

Specific Gravity – 1.90 g/cm³ .

Coverage – From 10 – 14 m²/kg at 60 microns film thickness.

Curing Schedule

Normal Cure:

6 minutes at 200ºC (Object Temperature)

10 minutes at 180°C (Object Temperature)

20 minutes at 160°C (Object Temperature)

Note:  to achieve matt finishes, the high temperature schedule is generally required.

Technical Properties

General

All tests carried out on degreased zinc-phosphated steel coated at 70mm and cured at 10 minute @ 180°C object temperature.



ECP 534 offers:



• Excellent static dissipation
• Good resistance to corrosion
• Good resistance against chemicals
• Excellent adhesion
• High surface hardness
• Limited gloss stability against UV exposure

Surface resistivity

<10⁹ W/sq ASTM D257

Charge decay 5000V – 50V <2 seconds JCI155

Pencil Hardness

1-3H

Flexibility-Bend Test

BS 3900: Part E1: 1970

Pass – 3/16 inch

Adhesion

Cross hatch BS 3900: Part E6: 1974

Classification Gt0 – no loss of adhesion

Erichsen-Cupping Test

BS 3900: Part E4: 1976

5 – 10 mm depending on colour and type.

Impact Test

10 – >160 kg cm according to colour and type.

Corrosion Resistance

Salt Spray

ASTM B117

More than 500 hours with creepage of corrosion less than 2mm from scribe mark.

Kersternich Test

DIN 50018 KFW2.0S

More than 10 cycles with creepage less than 2mm from scribe mark.

Humidity Test

BS3900: F2: 1973

More than 1000 hours without effect

Weathering Resistance

Poor

Chemical Resistance

Chemical resistance, like mechanical resistance tends to improve with higher temperature cure.

Excellent Resistance Against:

• Seawater
• Tap water
• Sulphuric acid, 20%
• Phosphoric acid 30%
• Sodium hydroxide 30%
• Acetic acid 20%
• High alcohols

Limited Resistance Against:

• Hydrochloric acid conc.
• Nitric acid 30%
• Petrol
• Aromatic solvents

Storage Stability

When stored in cool (<25ºC), dry conditions – 12 months.

Colours

Light grey as standard or other colours subject to MOQ

Health and Safety

See health and safety data sheets

This product does NOT contain Triglycidyl Isocyanurate (TGIC)
